FIAT DOBLO L2 DIESEL 1.5 Multijet 130 H1 Van Primo Auto

Images for illustration purposes only.

Key Information

Gearbox Automatic

Fuel Type Diesel

Bodytype Van

Load Height 1270mm

Load Length 2167mm

Load Width 1527mm

Payload 927kg

No. of Seats 3 Seats

Engine Size 1.5 litres

0 - 62mph 0.00s

Top Speed 114mph

Standard Equipment

Driver Convenience

10" digital instrumental cluster
Connected services
Cruise control and speed limiter
Driver attention alert level-4 with driver monitoring camera
Electronic power steering (EPS)
External temperature sensor
Intelligent speed assistance speed limit information
Lane keep assist
Lockable fuel cap
Multi-function on-board trip computer
Reverse parking sensors
Telematic box module with e-call
TPMS (Tyre pressure monitoring system)

Entertainment

Uconnect Infotainment system with Nav, 10" colour touchscreen, WiFi mirroring, AM/FM/DAB digital radio, Bluetooth, 2 USB, 2 speakers and 2 tweeters

Exterior Features

180 degree opening asymmetrical solid panel rear doors
Automatic headlight control
Black front bumper
Body colour rear bumper
Body colour side sliding door rail cover
Eco LED headlamps
Electric adjustable/heated door mirrors
Electrically operated front windows with one touch facility
High beam assist
High level third brake light
Integrated daytime running lights
Painted decor strips (Side mouldings)
Painted door handles
Painted exterior mirrors
Rain sensitive windscreen wipers
Short Antenna
Visible VIN at windscreen base

Interior Features

6 fixed floor mounted load restraint tie bracket points
6 way reach, rake, height and lumbar adjust comfort driver seat
AT shifting by e-Toggle
Audio Controls steering wheel buttons
Chrome air vents
Chrome interior door handle
Closed upper and open lower glove boxes
Dashboard storage areas
Double passenger bench seat with centre multi-purpose seat (shelf, seat, armrest, storage)
Driver seat armrest and adjustable headrest
Front door pockets with 1.5L bottle holder
Hard plastic floor protection in cabin
Hard plastic floor protection in load area
Load through bulkhead
Mica cloth upholstery
Mistral black dashboard
Overhead storage shelf in cabin
Reach and rake adjustable steering column
Sport steering wheel

Packs

Dynamic surround view pack with electric folding door mirrors - Doblo

Passive Safety

3x3 point seatbelts in 1st row
Automatic activation of hazard warning lights on major deceleration
Automatic door unlocking in event of accident
Curtain airbags
Door opening warning and audible lights on warning
Driver's airbag
Front passenger airbag
Outer front seats with height adjustable seatbelts + pretensioners
Seatbelt unfastened audible warning and warning light
Side airbags

Security

Dashboard mounted central locking push button and auto locking above 7mph
Deadlocking for passenger and cargo area
Perimeter and volumetric thatcham category 1 approved alarm with tilt sensor
Remote control central locking and deadlocking
Rolling code transponder immobiliser
Selective cabin and cargo area locking via 3-button plip remote control key (x2)

Technical

12v socket in dashboard
ABS
Advanced emergency braking system (AEBS)
Electronic brake force distribution
Electronic Stability Control (ESC)
Engine start/stop system
Hill start assist

Wheels

205/60 R16 96H XL Class A+ tyres

Technical Data

Emissions - ICE

HC

Not Available
Standard Emissions

EURO 6
WLTP - CO2 (g/km) - Comb - TEH

171
WLTP - CO2 (g/km) - Comb - TEL

143

Engine and Drive Train

Automatic Transmission

Yes
Bore

75
Catalytic Convertor

Yes
CC

1499
Cylinder Layout

IN-LINE
Cylinders

4
Engine Layout

FRONT TRANSVERSE
Engine Make

Not Available
Fuel Delivery

COMMON RAIL
Fuel Type

DIESEL
Gears

8 SPEED
Manual Transmission

No
Number of Valves

16
Stroke

84.8
Valve gear

DOHC

Fuel Consumption - ICE

EC

No
WLTP - FC (l/100km) - Comb - TEH

6.5
WLTP - FC (l/100km) - Comb - TEL

5.4
WLTP - MPG - Comb - TEH

43.4
WLTP - MPG - Comb - TEL

51.9

General

Alternative Fuel Qualifying

No
Did at least one aspect of this vehicles safety give cause for concern?

No
Badge Engine CC

1.5
Badge Power

130
Based On ID

Not Available
Chassis Engine Number

Not Available
Clutch

SINGLE DRY PLATE
Coin Description

Not Available
Coin Gross Vehicle Weight Code

Not Available
Coin Power Output Code

Not Available
Coin Series

Not Available
Coin Wheelbase Description Code

Not Available
Coin Wheelbase Name Code

Not Available
Exhaust System

Not Available
Front Brakes

VENTILATED DISCS
Front Suspension

MCPHERSON STRUT
Generation Mark

3
Ghost model for valuation purposes

No
Insurance Group 1

Not Available
Insurance Group 2

Not Available
NCAP Adult Occupant Protection %

Not Available
NCAP Child Occupant Protection %

Not Available
NCAP Front/Side Impact - Discontinued February 09

Not Available
NCAP Overall Rating - Effective February 09

Not Available
NCAP Overall Rating - LCV

4 Star
NCAP Pedestrian - Discontinued February 09

Not Available
NCAP Pedestrian Protection %

Not Available
NCAP Safety Assist %

Not Available
Rear Brakes

DISCS
Rear Suspension

COIL SPRINGS
Relative Height

H1
Relative Length

L2
Running Cost League Headings

SMALL
Service Interval Frequency - Months

24
Service Interval Mileage

25000
Special Edition

No
Special Order

No
Standard manufacturers warranty - Mileage

120000
Standard manufacturers warranty - Years

3
Steering

PAS
Timing Belt Interval Frequency - Months

120
Timing Belt Interval Mileage

125000
Vehicle Homologation Class

N1
Vin/Frame No.

Not Available

Performance

0 to 62

Not Available
BHP

131
Engine Power KW

96
Engine Power RPM

3750
Engine Torque LBS.FT

221
Engine Torque MKG

30.6
Engine Torque NM

300
Engine Torque RPM

1750
Top Speed

114

Test Cycles

Emissions Test Cycle

WLTP
RDE Certification Level

RDE 2

Tyres

Alloys?

No
Automatic Clutch

Yes
Plated 3rd Axle

Not Available
Plated 4th Axle

Not Available
Space Saver?

No
Tyre Make

Not Available
Tyre Size Front

205/60 R16
Tyre Size Rear

205/60 R16
Tyre Size Spare

TYRE REPAIR KIT
Wheel Style

Not Available
Wheel Type

16" STEEL

Vehicle Dimensions

Front Overhang

892
Height

1812
Height (including roof rails)

Not Available
Length

4753
Load Height

1270
Load Length

2167
Load Space Width Between Wheel Arches

1229
Load Width

1527
Lower Rear Door Width

1241
Rear Door Height

1196
Rear Overhang

886
Side Load Door Height

1072
Side Load Door Width

641
Turning Circle - Kerb to Kerb

11.3
Turning Circle - Wall to Wall

12
Upper Rear Door Width

1087
Wheelbase

2975
Width (excluding mirrors)

1848
Width (including mirrors)

2107

Weight and Capacities

Boot Capacity Saloons

Not Available
Fuel Tank Capacity (Litres)

50
Gross Train Weight

3400
Gross Vehicle Weight

2400
Load Space Volume

3.9
Luggage Capacity (Seats Down)

Not Available
Luggage Capacity (Seats Up)

Not Available
Luggage Capacity - 2nd Row Seats Removed

Not Available
Luggage Capacity - 2nd Row Seats Up

Not Available
Luggage Capacity - 3rd Row Seats Down

Not Available
Luggage Capacity - 3rd Row Seats Removed

Not Available
Luggage Capacity - 3rd Row Seats Up

Not Available
Max. Towing Weight - Braked

1000
Max. Towing Weight - Unbraked

750
Minimum Kerbweight

1473
No. of Seats

3
Payload

927
Plated 2nd Axle

1400
Plated Front Axle

1200
